Safely handle lightning currents up to 50 kA
ȋ Ȍ ǡ
Four conductors in the smallest of spaces
T
he PT 2,5/S-QUATTRO four-
conductor terminal blocks
with Push-in connection from
Phoenix Contact are now even
smaller and require even less
space in the control cabinet.
Thanks to their compact design,
ơ Ǥ
Up to four conductors that are up
to 2.5 mm² can be connected in one
feed-through terminal block. Tool-
free wiring of the pre-assembled
conductors is quick and easy. In
addition, ground terminals of the
same shape are also available.
These multi-conductor terminal
blocks are also characterized by
the double function shaft for easy
potential distribution with plug-
in bridges and the large-surface
marking options. Each current
path can be individually tested
for the terminal blocks. Thanks to
the consistent use of accessories
Phoenix Contact
from the Clipline complete
terminal block system, there are no
additional logistics costs.
T
he new FLT-SEC-PLUS 264 type 1 lightning current arresters
from Phoenix Contact are used in main supplies with 230/400 V
networks. Even in the event of high lightning currents up to 50 kA per
ǡ ơ Ǥ
prevents any line follow current.
The advantage of this is that the
load of the entire installation is
reduced to a minimum in the event
of lightning.
The compact design enables space-
ƪ Ǥ
A separate arrester backup fuse
is therefore no longer needed for
͜͜͡ Ǥ
available for protecting single and
three-phase power supply systems.
Downstream components are
protected due to the low voltage
protection level of the devices.
The easy-to-read status indicator
ƪ
contact keep the user informed
about the status of the devices at
all times. Recurring inspections of
the protective devices are carried
out quickly and easily with the
Checkmaster 2 test device.
